Best Deep Freezer in India at Reasonable Price - EVL-CFC 300 HT2 | Elista

EVL-CFC 300 HT2

  • Category: Best Deep Freezer in India at Reasonable Price
  • MRP: ₹ 200000
  • Voltage Range: 230 ±10%
    Plug Type: 3 Pin Plug Indian
    Product Dimensions (Including hinge and castor): 1105 X 720 X 845
    Net Weight KG: 52

Product Description

EVL-CFC 300 HT2

Lorem Ipsum is simply dummy text of the printing and typesetting industry. Lorem Ipsum has been the industry's standard dummy text ever since the 1500s, when an unknown printer took a galley of type and scrambled it to make a type specimen book. It has survived not only five centuries, but also the leap into electronic typesetting, remaining essentially unchanged.

Model Type HARD TOP

DIMENSION & WEIGHT

Product Dimensions (Including hinge and castor) W X D X H (MM): 1105 X 720 X 845
Packed Dimensions (Domestic) W X D X H (MM): 1175 X 760 X 900
Net Weight KG (±1kg): 52
Gross Weight KG (±3kg): 60
Net Capacity Ltrs. (Liter): 300
Compressor Compartment step Dimensions W x D (mm) W X D (MM): 670 X 250

ACCESSORIES

No of Baskets: 1
Baskets Dimenssion W X D X H (MM): 210 X 521 X 180
Ice scraper for Defrosting : 1
Door End Cap: Standard
Control Panel Design: Standard
Light: Yes
Handle: Recess/External
Lock & key: Yes

PRODUCT DISCRIPTION

Type Glossy
Outer & inner Body
Outer Material ( PP GI / Power coated) PPGI 0.35± mm Thk
Inner Material ( Stucco Al / PP GI) PPGI 0.45± mm Thk
Insulation
Puf thickness Lid 60
Puf thickness Cabinet 60
Blowing Agent Cyclopentane
Foaming density for cabinet 36 g/ml
Foaming density for door 38 g/ml
Evaporator Tube
Tube Material Al Tube
Alum Tube Diameter (OD) & Wall Thk (MM) ϕ7.90 / 0.7
Cu. Tube Diameter (OD) & Wall Thk (MM) ϕ6.35 / 0.5
Tube Length (m) 28.3Mtrs Wraping (Cooler 2, Freezer 11)
Fan Motor
Fan Motor Input & Output Power in Watts ± 5% 33W In / 5W In
30W In / 5W In
Voltage (V)/Hz 220~240V
50Hz
Fan Motor Speed (RPM) 1300 RPM
Fan Blade
Fan Material Type Aluminum
Fan Blade Type ( Throw / Suction) Suction
Fan Diameter (mm) X Angle Dia 200, 34℃
No of Blades 5
Refrigerant Type & Qty. R600a/R290/Gms. R290 - 85G

BODY COMPONENT

Wheel Type: Castor (360°)
Overall Wheel/Foot Height (mm): 50
No. of Holes in Gasket: 3

ELECTRICAL CIRCUIT

Voltage Range V AC
Plug Type Indian / Others 3 Pin Plug Indian
Plug Amp 6A / 13A 6A
Power Cord Length (outside machine ) Mtr 1.8
Thermostat Range for freezer Foshan KPF27U5 (-12 ~ -27)
Robertshaw (RCX -54007-05)

Additional Feature

Light YES
Handle Recess/External

The digital picture may slightly vary from the actual product for representation purpose.
